- Size: 120
- Place of Origin: Shandong,China
- Brand Name: Fudeng
- Model Number: FD-FOTT1
- Weight: 9000.000 kg
Quick Details
Use: | Truck Trailer | Type: | Semi-Trailer | Material: | Steel |
Certification: | CE CCC DOT ISO9001 | Size: | Buyer's Request | OEM No.: | Diesel fuel storage tank trailer |
Max Payload: | 45 - 100 Tons | Place of Origin: | Shandong, China (Mainland) | Brand Name: | Shandong Fudeng |
Model Number: | FD-FOTT49 | AXle No.&Brand: | 2/3/4 Axle FUWA/BPW/Chinese Brand | Suspension: | Mechanical |
Tire: | 11.00r20 12r22.5 315 385 | Color: | Custom's Requirement | Landing Gear: | Standard 28Ton |
Brake System: | WABCO | King pin: | 2"(50mm)or3.5"(90mm) JOST | Condition: | New |
Usage: | Transport Fuel oil | Keywords: | Diesel fuel storage tank trailer |
Packaging & Delivery
Packaging Details: | Nude packing. Bulk cargo or RORO shipping. semi-trailer. Low bed semi trailer,Container trailer. semi-trailer truck trailer.Pink tank semi trailer. Split gooseneck trailer, semi-trailer. Customer satisfaction is the goal we have been pursuing. |
Delivery Detail: | Shipped in 10 days after payment |
- Size: 120
- Place of Origin: Shandong,China
- Brand Name: Fudeng
- Model Number: FD-FOTT1
- Weight: 9000.000 kg
Main Dimensions | |
Tank Body | |
Shape | Round or Square |
Dimension | 12000mm*2490mm*3990mm or customized |
Volume(m3) | 25m³- 70 m³ |
Tare weight | About 6000KGS-12000KGS |
Tanker Body thickness | 5mm or 6mm/Q235 carbon steel/Q345B/aluminum/stainless steel |
End Plate thickness | 5mm or 6mm/Q235 carbon steel/Q345B/aluminum/stainless steel |
Manhole Cover | Carbon steel Aluminum alloy API manhole cover, 500mm |
Bottom Valve | Aluminum API Pneumatic Bottom Valve |
Discharging Valve | Diameter is 3 or 4 inch |
Discharging Pipe | 4” rubber hose, 2 pcs, 6m/each |
Compartments | Optional |
Cat Walk | With (Common model or special design) |
Chassis | |
Main Beams | Welding design or Special design I beam, connected by bolts and nuts Q345 carbon steel material |
Axle | 2 or 3 axles, BPW/FUWA/HUAJING brand |
Landing Gear | JOST (D200T)or CHINA BRAND 28T |
King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
Suspension | Mechanical suspension/Germany or America type/air suspension |
Leaf Spring | 90mm(W)*13mm(T)*10 Layer/90mm(W)*16mm(T)*10 Layer/ 100mm(W)*16mm(T)*10 Layer |
Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber (TKL brand); one piece of 45L air tanks. |
Rim | 9.00-22.5/8.00-20/8.5-20 China Brand |
Tire | 12.00R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be Optional |
ABS | Optional |
Accessories | One standard tool box |
Voltage | 24V |
Packing and shipping | |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping Terms | By Bulk Cargo/RORO/40HQ Containers |
