- Size: 120
- Place of Origin: Shandong,China
- Brand Name: Fudeng
- Model Number: FD-BBTT1
- Weight: 10000.000 kg
Quick Details
Use: | Truck Trailer | Type: | Semi-Trailer | Material: | Steel |
Certification: | CE CCC ISO | Size: | Buyer's Request | OEM No.: | Tractors for sale in south africa |
Max Payload: | 45 - 100 Tons | Place of Origin: | Shandong, China (Mainland) | Brand Name: | Shandong Fudeng |
Model Number: | FD-BBTT4 | Horsepower: | 336 - 420hp | Drive Wheel: | 6x4 |
Emission Standard: | Euro 2 | Driving Type: | Right Hand Driving | Tire: | 12R22.5 |
Wheel Number: | 10 | Engine Capacity: | > 8L | Color: | Customer's Requirement |
Condition: | New | Keywords: | Tractors for sale in south africa |
Packaging & Delivery
Packaging Details: | Nude packing. Bulk cargo or RORO shipping. Fudeng is China's most professional supplier of semi-trailer, the main products tank semi-trailer. Low bed semi-trailer,Container trailer. semi-trailer truck trailer.Pink tank semi trailer. Split gooseneck trailer, semi-trailer. Customer satisfaction is the goal we have been pursuing. |
Delivery Detail: | Shipped in 20 days after payment |
- Size: 120
- Place of Origin: Shandong,China
- Brand Name: Fudeng
- Model Number: FD-BBTT1
- Weight: 10000.000 kg
Traction | 6x4 | |||||
Driving type | LHD (RHD is in option) | |||||
Cabin
Tractor Truck
| North Benz cabin with A/C, two bunks Motor-driven Glass, 2 arm wind screen wiper system with 3 speeds, LCD Panel with LED light Major color of cab:Ice white lacquer color bar, date red lacquer, dolphin grey | |||||
Vehicle Main Dimensions | L*W*H(mm) | 7240x2500x3540 | ||||
Wheel base(mm) | 3450 1450mm | |||||
Wheel track(front/rear)(mm) | Front track (mm): 1995 Rear track (mm): 1800/1800 | |||||
Approach/Departure angle(°) | 16 / 60 | |||||
Overhang (front/rear)(mm) | 1515/825 | |||||
Weight in KGS | Tare Weight(kg) | 8800kg | ||||
Trailer Total mass (kg) | 40000kg | |||||
Max trailing mass on 5th wheel | 25000kg | |||||
Front axle loading capacity | 7.5tons | |||||
Rear axle loading capacity | 2x18tons | |||||
Engine | Brand | Wei chai | ||||
Emission | EURIII | |||||
Engine type | Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter-cooling | |||||
Displacement | 9.726L /Diesel | |||||
Max. output | 420hp@1900rpm | |||||
Max torque | 1400NM@1200-1600rpm | |||||
Bore/Stroke(mm) | 126/130 | |||||
Specific fuel consumption | 198g/Kwh | |||||
Fuel tank | 400L Aluminum Tank | |||||
Front axle | Double-shoe pneumatic brake, non-driving steering axle | |||||
Rear axle | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | |||||
Gradeability | 28% | |||||
Brake system | Double-circulate brake system, 60L Air tank, Higher Air Pressure, 220mm Brake pad, Air chamber 30/24'' | |||||
Service brake | Brake gap can be adjusted automatically, double circulation air brake system | |||||
Assistant brake | Engine exhaust brake | |||||
Park brake | Potential springs pressing on middle and rear wheels |
